monitor consumption, a flexible data acquisition system In each area an Operator control cabin (CT-CR) and
is designed, composed by a remote I/O system, some Power and Control cabins (CT-PC) are
capable of collecting all signals of each substation. required.
All the collected signals are then conveyed to the
central Supervision system of the material Handling The three Control Operator cabins represent the “pivot”
plant, where the operator has the possibility to have a of the system and they can be considered
complete view of the status of the electrical distribution interchangeable, since in the event one of the three
system. doesn’t functions, the others can intervene on the
The communication between the data acquisition entire system, thus preventing malfunctions.
system and supervision software (SCADA) happens
through a Modbus TCP / IP protocol communication These cabins (CT-CR) are designed to host:
with copper converter - Fiber Optic (for long distances), • Operator Station (Client PC and printer)
that is configured with the aim of: • Server
• show the status of the circuit breakers and act on • Main PLC panels
them (on the Medium Voltage side); • UPS
• show the electrical parameters coming from the • Electrical Auxiliary panels
network analyzers,
• communicate with the generators; The power and control cabins (CT-PC), instead host
• report and historicize alarms of protection relay. mainly:
• Power & Control panels complete of PLC remote I/O,
The supervision system allows to save the sequence of inverter and softstarter
events recorded on text files or on an excel / database, • Electrical Auxiliary panels
in order to process and manage them for the purpose
of analyzing the energy performance of the system The automation system of the plant manages around
directly on site or through a via web access. 1700 input and 600 output (digital and analogic) and
it’s based on a platform known to the industrial market
for its functionality addressed to the world of industry
The “Downstream” system 4.0 and for the possibility of creating multi-users,
The “Downstream” side, namely the Automation improving diagnostics (also related to energy
system of the Material Handling plant, is divided in 3 management), cloud connectivity and boosting plant
macro area, each of them is able to operate productivity.
independently: The system architecture is foreseing a Client-Server
- Primary Area type SCADA supervision, composed by two servers
- Secondary/ Tertiary/Quaternary Area and four Operator Station (OS).
- RCC Precooling e Mixing Plant Area The SCADA system is distributed in three control
cabins (CR1, CR2 and CR3), with an Operator Station
(OS) for each Operator Control cabin, in order to give
the possibility to the operator to have a complete
control of its area of competence.
In case of need or unavailability of one of the Operator
Stations, the plant could be managed by the other OS
in the other Operator Control cabins.
A fourth OS station is placed in offices located in a
remote area and allows the personnel to supervise all
plant’s areas.

The automation system is based on
a platform known to the industrial
market for its functionality addressed
to the world of ‘industry 4.0’ and
for the possibility of creating multi-
users, improving diagnostics, cloud
connectivity and for boosting plant
productivity

The “heart” of the system in which all data is collected
